Zero #567B Rabbeted Threshold, 5" (W) Bronze with Neoprene and Grip Saddle, .5" H

Zero #567B Rabbeted Threshold, 5" (W) Bronze with Neoprene and Grip Saddle, .5" H
Zero International
Read 1 review

This Zero #566B ADA compliant rabbeted threshold is fitted with a neoprene gasket and extruded bulb finger, which provides a solid seal against dust, drafts, insects and water infiltration. It is fire and smoke rated and crafted from heavy duty bronze mill finish (brass). Grooves on the saddle prevent slipping. Options of epoxy abrasives and full body strength available. Length is custom cut to size.

PRICED PER FOOT

See tabs below for additional information
    • SKU
      ZR567-B
      • 19% off
      Market price: $95.63 save $18.17
    • Starting price: Price: $77.46 per foot


    Threshold spans under doors and has a solid neoprene seal which compresses against a closed door to ensure a superior seal. Saddle design has a flat top surface which works well with a Surface Mounted Automatic Door Bottom.

    Total Width: 5"

    Width Under Door: 1.75"

    Required Door Clearance: .375"

    Total Height: .5"

    Thickness: .125"

    Length: Custom cut to size up to 104" (Larger sizes can be purchased through our office)

    Finish: Bronze Mill Finish (Oil Rubbed Bronze can also be purchased for an additional 49% of standard bronze price)

    Compliance Details: Positive Pressure Fire Rating, Smoke Rating, ITS Warnock Hersey Listed, ADA / Wheelchair Compliance

    Seal: Solid Neoprene EBF (Extruded Bulb and Finger Design). The bulb has great compression properties while the additional finger aids in sealing extra gaps due to misalignment during installation or natural warping of the door. Solid neoprene will remain effective in extreme weather conditions.

    Installation: Installation instructions and screws provided. If threshold is being drilled into concrete, Expansion Anchors are recommended.

    Drilling: Threshold is drilled for easy installation

    Additional Options Include:

    • Non-Stick Epoxy Abrasives can be bonded into the grooves. The tread provides a coefficient of friction of 1.02 dry and 0.98 wet to comply with ADA, OSHA and most local building codes requirements.
    • Full Body Strength: An aluminum composite filler containing aluminum oxide and silicone carbide. Ideal applications include heavy commercial traffic in supply rooms, manufacturing buildings, schools, cafeterias, automobile dealers, hospitals, industrial facilities.

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See product specs for exact measurements.

    This product has a 1 year guarantee against defects in material and workmanship.
    Click here to view our full Warranty Policy.

    This threshold is also available in an Aluminum version, see our Zero International #566A 5" Aluminum Rabbeted Threshold with Grip Saddle.

      • SKU
        ZR567-B
    • QuickShip
      No
    • Manufacturer
      Zero International
    • MPN
      566B
    • Options
      Standard Bronze, Epoxy Abrasives, Full Body Strength, Both Epoxy and Full Body
    • Dimensions
      • Overall Height
        .5" Height
      • Overall Width
        .5" Width
      • Threshold Length
        Custom Cut to Size
      • Required Door Clearance
        .375" Height
      • Thickness
        .125" Thick
    • Product Design
      • Flat Saddle Design
        Fluted (Grooved) Design
      • Threshold Type
        Rubber Seal / Bumper Threshold
      • Seal Type
        Neoprene Seal
      • Material
        Bronze
    • Installation
      • Drilling Holes
        Drilling holes provided
      • Fasteners
        Fasteners Provided
    • Finishes
      • Finish
        Bronze Mill Finish (Brass)
    • Compliance Details
      • Warranty
        1 Year Limited Warranty
    5.0
    1 Review
    100% would recommend this to a friend

    Ratings Distribution

    5 Stars 100 1
    4 Stars 0 0
    3 Stars 0 0
    2 Stars 0 0
    1 Star 0 0

    Pros

    • 1 Good Design

    Reviewed by 1 customer

    5

    Threshold

    Comments about Zero #567B Rabbeted Threshold, 5" (W) Bronze with Neoprene and Grip Saddle, .5" H

    The job came out nice but it was a nightmare to cut and match the profile on the bottom of an existing frame with a side light. For this it should come with a template.

    By Constantino
    Verified Buyer

    Click to Print

    product specs z567








    SHIPPING / PROCESSING TIME:

    This product ships directly from the manufacturer.
    This product ships directly from the manufacturer.
    Please allow 2 - 3 weeks to ship



    • Domestic Shipping Fees- (Hawaii and Alaska not Included):
      • FREE SHIPPING on orders over $300.00 (excludes oversized and freight orders).
      • There will be a flat $19.99 shipping and handling fee on orders under $300.00.
      • Oversize: Orders containing items sized 50" - 95" have an oversize surcharge of $49.99.
      • Freight Items: Orders containing items sized 96" - 108" have an oversize surcharge of $199.99.
      • Oversize Freight Items: Orders containing items sized 109" and above have an oversize surcharge of $299.99.
      • Orders totals above $2,000.00 will ship free, regardless of size.

    • Alaska and Hawaii, Canada, and International Shipping:
    • Returns:
      • This product is custom made and is not returnable.
      • We are committed to your satisfaction, as a courtesy, we may, at our discretion accept returns with a minimum 30% restock fee.
      • CLAIMS FOR SHORTAGE OR DAMAGE IN TRANSIT: All claims must be made within Seven (7) days of receipt of goods.
      • Weatherstripping products will not be considered for returns.
      • Item must be in new, re-saleable condition.
      • Please call or email us to receive an RMA number before returning. No returns will be processed without an RMA number.
      • Return shipping is customer's responsibility. A return address will be provided with RMA#.
      • If you are shipping via USPS (not recommended) do NOT require signature as we will not be able to pick up your package from local post office facility.
