Pemko #309P Door Sweep and Perimeter Gasket, .875" Aluminum with .375" Pile Brush

This aluminum door gasket and door bottom sweep has a pile insert which will seal gaps around your door to prevent infiltration of air, smoke, fire, drafts and insects. Available in a selection of aluminum finishes and is custom cut to size.

A pile brush is a soft brush, similar to a baby brush bristles. For a more rigid brush, see our Pemko #309N with Nylon Brush.

PRICED PER FOOT

See tabs below for additional information

Finish
Size

Quantity

Add to compare

This aluminum door seal can be applied as a door bottom sweep or a perimeter door gasket. Its flexible pile insert compresses easily to create a seal that will prevent infiltration of smoke, fire, fumes, air, drafts and insect through the gap around doors. High quality bristles create a strong seal while ensuring low closing force.

As a door bottom sweep, it can fill gaps of .375". When used as a door gasket application, it is designed to seal up to 1/16", however it can seal up to the depth of its seal. The casing is punched with elongates slots for easy adjustment once it is installed.

A pile brush is a soft brush, similar to a baby brush bristles. For a more rigid brush, see our Pemko #309N with Nylon Brush.

Installation instructions and screws provided.

Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See product specs for exact measurements.

This product has a 5 year guarantee against defects in material and workmanship.
Click to view our Full Warranty Policy.

Click here to see more Pemko Door Sweeps.

- SKU
  PK309AP
QuickShip
No
Manufacturer
Pemko Manufacturing
MPN
309
About this Product
- Door Shoe Retainer Material
  Aluminum
- Door Type
  Wooden Door, Metal Door
- Seal Type
  Soft Brush Seal
- Mounting
  Surface Mounted
Dimensions
- Seal Height
  3/8" Height
- Total Height
  1-2/8" Height
- Additional Dimensions
  Door seal is 1/4" thick
- Length
  Custom Cut to Size
Installation
- Drill Holes
  Drill holes are provided
Finishes
- Finish
  Mill Finish Aluminum (US27), Clear Anodized Aluminum (US28), Oil Rubbed Bronze, Equiv. (10BE), White Suede Powder Coat, Black Suede Powder Coat
Compliance Details
- Compliance Details
  UL Classified, Fire Rated, Smoke Rated
- Warranty
  5 Year Limited Warranty

Click to Print

P309 Product Specs:

Click to Print

P309 Product Specs:

Click to View our Ratings Explained

Finishes Comply with the Following ANSI / BHMA Codes:

Aluminum Mill Finish - US27 / 719
Clear Anodized Aluminum - US28 / 628
Dark Bronze Anodized Aluminum - US10B / 710
Bright Dip Gold Anodized Aluminum - US3 / 707
Gold Anodized Aluminum - US4 / 688
Satin Nickel Anodized Aluminum - US15 / 619
Painted White Aluminum - 714

SHIPPING / PROCESSING TIME:

This product ships directly from the manufacturer.

Please allow 2 - 3 weeks to ship

Domestic Shipping Fees- (Hawaii and Alaska not Included):
- FREE SHIPPING on orders over $300.00 (excludes oversized and freight orders).
- There will be a flat $19.99 shipping and handling fee on orders under $300.00.
- Oversize: Orders containing items sized 50" - 95" have an oversize surcharge of $49.99.
- Freight Items: Orders containing items sized 96" - 108" have an oversize surcharge of $199.00.
- Oversize Freight Items: Orders containing items sized 109" and above have an oversize surcharge of $299.99.
- Orders totals above $2,000.00 will ship free, regardless of size.
Alaska and Hawaii, Canada, and International Shipping:
- Please see our Shipping Information page for details.
Returns:
- This product is custom made and is not returnable.
- We are committed to your satisfaction, as a courtesy, we may, at our discretion accept returns with a minimum 35% restock fee.
- CLAIMS FOR SHORTAGE OR DAMAGE IN TRANSIT: All claims must be made within Seven (7) days of receipt of goods.
- Weatherstripping products will not be considered for returns.
- Item must be in new, re-saleable condition.
- Please call or email us to receive an RMA number before returning. No returns will be processed without an RMA number.
- Return shipping is customer's responsibility. A return address will be provided with RMA#.
- If you are shipping via USPS (not recommended) do NOT require signature as we will not be able to pick up your package from local post office facility.
