Hawa Concepta 25, 30, 40, or 50 - Single Pocket Pivot Door System, Doors to 110 LB

Hawa Concepta installed as a closet
  • Contractors Choice
Hawa / EKU Sliding Solutions
Read 1 review

Hawa Concepta 25 - 50 is a Concealed Pocket Pivot Sliding System for single, oversized pocket pivot doors. Designed with a unique scissor technology to accommodate large and heavy doors. Door is pulled automatically into pocket for smooth operations. Available in choice of models, see below for sizing and weight guidelines. Hardware includes all necessary components to install 1 wooden door.

PRICED PER SET

See tabs below for additional information
    • SKU
      HF408.30.590
      • 10% off
      Market price: $1,853.67 save $185.37
    • Starting price: Price: $1,668.30 per set
    Additional discounts will be applied when added to cart!


    Hafele Hawa Concepta 25 / 30 / 40 / 50 is a concealed pocket pivot door for single, large and heavy doors, click to view the HAWA Concepta 50 Catalog.

    Door Dimensions:

    Model #
    Door Height
    Door Width
    Door Weight
    Item #
    Hawa Concepta 25
    49" to 72-3/16"
    11-13/16" to 29-1/2"
    55 LB (25 kg)
    408.30.045
    Hawa Concepta 30
    72-7/8" to 90-3/16"
    11-13/16" to 35-7/16"
    66 LB (30 Kg)
    408.30.046
    Hawa Concepta 40
    72-7/8" to 98-7/16"
    11-13/16" to 35-7/16"
    88 LB (40 Kg)
    408.30.047
    Hawa Concepta 50
    90-9/16" to 112-3/16"
    11-13/16" to 35-7/16"
    110 Lb (50 Kg)
    408.30.048


    Sliding Features:

    • For laterally sliding-in cabinet doors
    • Unique scissor technology accomodates large and heavy doors
    • Door is pulled into pocket automatically
    • Suitable for room partitioning, as there is no need for a base or top panel in wall recesses.
    • All adjustments are made from the front of the cabinet

    Handing: For right and left hand use.

    Single Sliding: Set is for one door. For double door bi-parting system, purchase quantity of 2.

    Door Thickness:

    • Wood: 3/4" - 1-15/16" Thick
    • Rabbeted: >1-13/16" - 1-15/16" Thick
    All Sets Include:Additional Supplied Components
    • 1 scissor assembly complete with 2 guides
    • 1 spacer profile
    • 1 door stopper with clip-in stopper
    • 3 alternative profiles and brushes
    • 1 pair of cover caps
    • 1 end position damper
    • 1 self closing mechanism for door
    • 1 soft stopper bracket
    • Mounting instructions
    • Hawa Concepta 25 / 30:
      • 1 Upright with 2 play-free guides
      • 3 Concealed Hinges
      • 2 Guide Tracks
    • Hawa Concepta 40:
      • 1 Upright with 2 play-free guides
      • 4 Concealed Hinges
      • 1 Guide Tracks
      • 1 Running Track
    • Hawa Concepta 50:
      • 1 Upright with 2 play-free guides
      • 5 Concealed Hinges
      • 1 Guide Track
      • 1 Running Track

    Optional Accessories for Overlay Doors on Top and Bottom:

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail.

    This product has a 1 year guarantee against defects in material and workmanship.
